O11 DYNAMIC EVO XL - THE ULTIMATE O11 EVOLUTION
Introducing the all-new O11D EVO XL, an enlarged case that accommodates numerous components while enhancing modularity to meet the needs of most PC enthusiasts.

FINE MESH, EQUISITE TOUCH
Keeping style and performance in mind, both the top and side panels of the O11D EVO XL are crafted from aluminum with fine mesh, providing a high-end appearance yet delivering superior cooling compared to the O11D XL. The fully open bottom panel, along with three dust filters ensures uncompromised airflow while effectively keeping dust out of the chassis.

COMPLETE SEEMLESS VIEW
The O11D EVO XL’s front pillar can now be easily removed, providing an unobstructed view for showcasing hardware without affecting the case’s structure.

BIG SIZE, GREAT COMPATIBILITY
Plenty of space is available in the O11D EVO XL for accommodating modern, powerful, and large components. There’s also sufficient cooling with the support for 3 × 420mm radiators. All 3 sides can hold up to a maximum of 420mm radiator.

FLEXIBLE CONFIGURATION
The adjustable motherboard tray can move up and down with three levels of height to fit different fan and radiator combination. The motherboard tray supports a maximum of E-ATX (width 280mm) motherboard.

STRUGGLE-FREE FAN BRACKETS
Equipped with quick-release design, the fan brackets can be easily removed or installed. Top Fan Bracket - Removable from the top. Bottom Fan Bracket - Removable from the main chamber. The side bracket can be oriented in two ways depending on how you set up the fan intake/exhaust or position. Side Fan Bracket - Removable with a quick-latch. Comes with 2 seal plates to ensure no air pressure leak is created when mounting a 360mm radiator or 3 × 120mm fan on the side. The plates can be adjusted and moved around based on the configuration. Inner Scenario - Supports up to 81mm thick radiator/ fan combo in the main chamber (40mm in the second chamber). Outer Scenario - Supports up to 117.2 mm thick radiator/ fan combo in the main chamber.

RELOCATABLE I/O PORT
To satisfy any need, the modular I/O port includes 1 × USB Type C and 4 × USB Type A ports. At the bottom of the chassis, the I/O module can be relocated to 3 different locations without the use of any tools.

FRIENDLY STORAGE CAPACITY
Offers multiple easily accessible storage mounting locations that support up to 7 × SSDs or 4 × HDDs + 3 × SSDs.

WITH WATER COOLING IN MIND
Offers a hidden mounting point for D5 or DDC pump, accessible by removing the bottom drive cage in both reverse and normal modes.

CUSTOMIZABLE CABLE MANAGEMENT
The O11D EVO XL comes with 3 dual-layer cable clips that can be mounted anywhere along vertical grommets pass through, providing versatility for your cable routing plan.

SPECIFICATIONS
CASE TYPE: Tower Chassis
COLOR: Black
DIMENSIONS: (D) 522mm x (W) 304mm x (H) 531.9mm
MATERIAL: Steel, 4.0mm Tempered Glass, Aluminum
MOTHERBOARD SUPPORT: E-ATX (Under 280mm)/ATX/Micro-ATX/Mini-ITX
EXPANSION SLOT: 8
STORAGE : Behind MB Tray: 3 x 2.5” SSD Hard Drive Cage: 4 x 3.5” HDD / 2.5” SSD
GPU LENGTH CLEARANCE: 460mm (Max.)
CPU COOLER HEIGHT CLEARANCE: 167mm (Max.)
PSU: ATX (Under 220mm)
FAN SUPPORT: Top: 3 x 120mm / 3 x 140mm Side: 3 x 120mm / 3 x 140mm Bottom: 3 x 120mm / 3 x 140mm Rear: Up to 2x 120mm
RADIATOR SUPPORT: Top: 360 / 420 / 240 / 280mm Side: 360 / 420 / 240 / 280mm Bottom: 360 / 420 / 240 / 280mm
I/O PORTS: 1 x Power Button 1 x Reset Button 4 x USB 3.0 1 x USB Type C 1 x Audio 1 x LED Color Button 1 x LED Mode Button
DUST FILTERS: 1 x Bottom 1 x Top 2 x Side
