Opis
General Feature
Application Client PCs
Capacity 2,000 GB (1 GB=1 Billion byte by IDEMA)
Form Factor 2.5 inch
Interface SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
Dimension (WxHxD) 100 X 69.85 X 6.8 (mm)
Weight Approx. 60.0g Weight
Storage Memory Samsung V-NAND 4bit MLC
Controller Samsung MJX Controller
Cache Memory Samsung 2 GB Low Power DDR4 SDRAM
Special Feature
TRIM Support TRIM Supported
S.M.A.R.T Support S.M.A.R.T Supported
GC (Garbage Collection) Auto Garbage Collection Algorithm
Encryption Support AES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive)
WWN Support World Wide Name supported
Device Sleep Mode Support Yes
Performance
Sequential Read Up to 550 MB/s Sequential Read * Performance may vary based on system hardware & configuration
Sequential Write Up to 520 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Read (4KB, QD32) Up to 97,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Write (4KB, QD32) Up to 89,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Read (4KB, QD1) Up to 7,500 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Write (4KB, QD1) Up to 42,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Environment
Average Power Consumption (system level) Average: 3.1 W *Maximum: 4.2 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle) Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage 5V ± 5% Allowable voltage
Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
Operating Temperature 0 - 70 C Operating Temperature
Shock 1,500 G & 0.5 ms (Half sine)
Accessories
Installation Kit Not Available
Software
Management SW Magician Software for SSD management
Warranty
3 Years Limited Warranty or 720 TBW Limited Warranty
