Opis

Raptor Canyon i9
NUC 13 Extreme NUC13RNGi9


Processor Intel® 13th Gen Core™ i9-13900K; 8P+16E/32T; P-Cores: up to 5.8 GHz - E-Cores: up to 4.3 GHz; 36MB Intel® Smart Cache; 125W Unlocked TDP

Graphics Intel® UHD Graphics 770 up to 1.65 GHz; 1x HDMI 2.1 TDMS; 2x Thunderbolt™ 4 (Alt-DP); 1x PCIe x16 Gen5 socket up to 450W; Triple-slot GPU capable; Max Length: 313mm; Max Slot Thickness: 63mm; Max Card Height:155mm; Max Backplate Thickness: 3.5mm

Memory Dual DDR5 SODIMMs 1.2V; 64GB Max; Up to 5600MHz

Storage
1x M.2 22x80 M-Key x4 PCIe supporting NVMe Gen4 (512GB to 4TB), Gen3 (128GB to 8TB); 2x M.2 22x80 M-Key x4 PCIe supporting NVMe Gen4 (512GB to 4TB), Gen3 (128GB to 8TB) and SATA SSD (128GB to 2TB); M.2 M-Key slots RAID-0 & RAID-1 Capable; 2x SATA headers for single 3.5” or dual 2.5” drives supporting SATA SSD (128GB to 8TB)

Peripherals Intel® Wi-Fi 6E AX1690i; Bluetooth 5.2; 1x 10Gb LAN (AQC113); 1x 2.5Gb LAN (i225-LM); 2x Thunderbolt 4; 6x USB 3.2 Gen2 Type-A; 2x USB 3.2 Gen1 Type-A; 1x USB 3.2 Gen2 Type-C

Chassis 337 x 318 x 129 mm (<14L volume); Kensington Lock; 2x 120mm system fans

Expansion 2x SATA ports; 2x 12V PWM Fan headers; USB 3.2 Gen 2 header; DC power for SATA HDDs; 4 addressable RGB headers supporting up to 120 LEDs
Audio 3.5mm front stereo headset jack; Analog audio with discrete Mic-in, Line-in, Speaker-out, FP audio Header; 7.1 multichannel audio via HDMI or DisplayPort (Type-C)

Power Full modular - 750W 80+ Gold SFX 12VO internal power supply


Customization
Primary storage sockets supporting up to NVMe Gen4 available up to 4TB, up to 8TB Gen3
Secondary and tertiary storage sockets supporting up to NVMe Gen4 available up to 4TB, up to 8TB Gen3 or SATA SSD up to 2TB
Dual 2.5” drives up to 8TB SATA per drive Memory up to 64GB
Full-Length triple-slot GPU Support
OS options including Windows 10/11, Windows Server 2019, Ubuntu
