General Feature
Application Client PCs
Capacity 1,000 GB (1 GB=1 Billion byte by IDEMA)
Form Factor 2.5 inch
Interface SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
Dimension (WxHxD) 100 X 69.85 X 6.8 (mm)
Weight Approx. 46.0g Weight
Storage Memory Samsung V-NAND 4bit MLC
Controller Samsung MKX Controller
Cache Memory Samsung 1 GB Low Power DDR4 SDRAM

Special Feature
TRIM Support TRIM Supported
S.M.A.R.T Support S.M.A.R.T Supported
GC (Garbage Collection) Auto Garbage Collection Algorithm
Encryption Support AES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive)
WWN Support World Wide Name supported
Device Sleep Mode Support Yes

Performance
Sequential Read Up to 560 MB/s Sequential Read
Sequential Write Up to 530 MB/s Sequential Write
Random Read (4KB, QD32) Up to 98,000 IOPS Random Read
Random Write (4KB, QD32) Up to 88,000 IOPS Random Write
Random Read (4KB, QD1) Up to 11,000 IOPS Random Read
Random Write (4KB, QD1) Up to 35,000 IOPS Random Write

Environment
Average Power Consumption (system level) Average: 2.2 W *Maximum: 4.0 W (Burst mode)
Power consumption (Idle) Max. 30 mW
Allowable Voltage 5V ± 5% Allowable voltage
Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
Operating Temperature 0 - 70 ? Operating Temperature
Shock 1,500 G & 0.5 ms (Half sine)

Software
Management SW Magician Software for SSD management

Warranty
3 Years Limited Warranty or 360 TBW Limited Warranty
