General Feature
Application Client PCs
Capacity 250GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor M.2 (2280)
Interface PCIe Gen 4.0 x4, NVMe 1.3c
Dimension (WxHxD) 80.15 x 22.15 x 2.38 (mm)
Weight Max 9.0 g Weight
Storage Memory Samsung V-NAND 3-bit MLC
Controller Samsung Elpis Controller
Cache Memory Samsung 512MB Low Power DDR4 SDRAM

Special Feature
TRIM Support Supported
S.M.A.R.T Support Supported
GC (Garbage Collection) Auto Garbage Collection Algorithm
Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support Not supported
Device Sleep Mode Support Yes

Performance
Sequential Read Up to 6,400 MB/s * Performance may vary based on system hardware & configuration
Sequential Write Up to 2,700 MB/s * Performance may vary based on system hardware & configuration
Random Read (4KB, QD32) Up to 500,000 IOPS* Performance may vary based on system hardware & configuration
Random Write (4KB, QD32) Up to 600,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4KB, QD1) Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD1) Up to 60,000 IOPS * Performance may vary based on system hardware & configuration

Environment
Average Power Consumption (system level) *Average: 5.9 W *Maximum: 7.4 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle) Max. 35 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage 3.3 V ± 5 % Allowable voltage
Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
Operating Temperature 0 - 70 ? Operating Temperature
Shock 1,500 G & 0.5 ms (Half sine)

Accessories
Installation Kit Not Available

Software
Management SW Magician Software for SSD management

Warranty
5-Year Limited Warrantyor 300 TBW Limited Warranty
